1980 KALININ FACTORY KB3537, 500T Double-crank sheet stamping press
orCall +44 20 3287 0537
Specifications
| Manufacturer | KALININ FACTORY |
| Model | KB3537, 500T |
| Year | 1980 |
| Stock Number | 164819214 |
| Nominal force | 500 ton |
| Slide stroke | 250 mm |
| Slide strokes per minute | 25 |
| Table dimensions | 1400 x 2500 mm |
| Of adjustment | 750 mm |
| Press weight | 69000 kg |
Description
Nominal force: 500 ton
Slide stroke: 250 mm
Slide strokes per minute: 25
Table dimensions: 1400 x 2500 mm
Max distance between table and slide in its lower position at the upper position of adjustment: 750 mm
Size of distance adjustment between table and slide: 250 mm
Press dimensions (Length x Width x Height): 4130 x 2945 x 7200 mm
Press weight: 69000 kg
